Boss's Legendary Super Overdrive Sound
Since its release in 1981, the workhorse SD-1 Super Overdrive has been the core gain pedal for generations of players across every musical genre. Based around the revolutionary asymmetrical clipping circuit from the OD-1 Overdrive - one of the three original BOSS compact pedals from 1977 - the SD-1 delivers rich, smooth and highly musical overdrive tones that continue to inspire guitarists everywhere.
Standard Features
- Genre-defining BOSS overdrive sound
- Unique asymmetrical clipping circuit produces tube-like overdrive characteristics
- Mild to moderate drive tones with focused midrange and tight low end
- Ideal for use with clean and slightly drive amps
- Also works great for bringing tightness and definition to high gain amp tones
- Stacks well with boost, overdrive and distortion pedals
Specifications
| Nominal Input Level | -20 dBu |
| Input Impedance | 1 M ohm |
| Nominal Output Level | -20 dBu |
| Output Impedance | 1k ohm |
| Recommended Load Impedance | 10k ohms or greater |
| Bypass | Buffered bypass |
| Control | Drive Knob, Tone Knob, Level Knob, Pedal Switch |
| Indicator | Check indicator (Used for indication of check battery) |
| Connectors | Input & Output Jack : 1/4 inch phone type DC In Jack |
| Power Supply | Carbon Zinc Battery (9V, 6F22) or Alkaline Battery (9V, 6LR61), AC adaptor (PSA Series : Sold Separately) |
| Current Draw | 10mA |
| Expected Battery Life Under Continuous Use | Carbon : Approx 60 hours Alkaline : Approx 90 hours *These figures will vary depending on the actual conditions of use* |
| Options (Sold Separately) | AC Adapter : PSA Series |
Size & Weight
| Width | 73mm 2-7/8 inches |
| Depth | 129mm 5-1/8 inches |
| Height | 59mm 2-3/8 inches |
| Weight | 360g 13oz |
